Features
- “Adaptive Speed and Torque Technology” to ensure a lasting, constant and smooth speed during movement.
- Four safety inputs which can be configured to directly manage the (8k2Ω) resistive sensitive safety-edges.
- Set up to fit the 806SA-0120 clock control board for managing up to eight settings for opening and closing maneuvers.
- Control board with terminal blocks, graphic display and storage for up to 250 users.
- User-friendly release lever for manually opening the gate.
- Protection rating against weathering agents (IP54).
- Ready for installation of magnetic limit switches (001RSDN002).
- Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.
Technical Specification
| MODELS | 801MS-0300 | 801MS-0310 | 801MS-0320 | 801MS-0350 | 801MS-0360 | 801MS-0370 | 801MS-0330 | 801MS-0340 |
|---|---|---|---|---|---|---|---|---|
| Protection rating (IP) | 54 | 54 | 54 | 54 | 54 | 54 | 54 | 54 |
| Power supply (V – 50/60 Hz) | 230 AC | 230 AC | 230 AC | 230 AC | 230 AC | 230 AC | 120 AC | 120 AC |
| Power supply to motor (V) | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC | 36 DC |
| Absorption (A) | 8 | 9 | 10 MAX | 8 | 9 | 10 MAX | 8 | 9 |
| Power (W) | 200 | 250 | 300 | 200 | 250 | 300 | 200 | 250 |
| Manouvering speed (m/min) | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Cycles/Hour | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE | CONTINUOUS SERVICE |
| Thrust (N) | 800 | 900 | 1000 | 800 | 900 | 1000 | 800 | 900 |
| Operating temperature (°C) | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 | -20 ÷ +55 |
Models
Complete operators with 36 V DC geared motor
801MS-0300
BKV15AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement and obstruction detecting device for sliding gates weighing up to 1500 kg that are up to 20-m long. RAL7024-grey cover.
BKV15AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement and obstruction detecting device for sliding gates weighing up to 1500 kg that are up to 20-m long. RAL7024-grey cover.
801MS-0310
BKV20AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement and obstruction detecting device for sliding gates weighing up to 2000 kg that are up to 20-m long. RAL7024-grey cover.
BKV20AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement and obstruction detecting device for sliding gates weighing up to 2000 kg that are up to 20-m long. RAL7024-grey cover.
801MS-0320
BKV25AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement management/obstruction detection and module 6 pinion for sliding gates weighing up to 2500 kg that are up to 20-m long. RAL7024-grey cover.
BKV25AGS – Operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, movement management/obstruction detection and module 6 pinion for sliding gates weighing up to 2500 kg that are up to 20-m long. RAL7024-grey cover.
Complete operators with 36 V DC gearmotor – PLUS Version
801MS-0350
BKV15AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, magnetic limit switches and clock accessory included for sliding gates weighing up to 1500 kg that are up to 20-m long. RAL7024-grey cover.
BKV15AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, magnetic limit switches and clock accessory included for sliding gates weighing up to 1500 kg that are up to 20-m long. RAL7024-grey cover.
801MS-0360
BKV20AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, magnetic limit switches and clock accessory included for sliding gates weighing up to 2000 kg that are up to 20-m long. RAL7024-grey cover.
BKV20AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, magnetic limit switches and clock accessory included for sliding gates weighing up to 2000 kg that are up to 20-m long. RAL7024-grey cover.
801MS-0370
BKV25AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, module 6 pinion, magnetic limit switches and clock accessory included for sliding gates weighing up to 2500 kg that are up to 20-m long. RAL7024-grey cover.
BKV25AGE – Plus version operator with 36 V motor, featuring a control board with graphic display, Adaptive Speed & Torque Technology, 4 safety inputs, module 6 pinion, magnetic limit switches and clock accessory included for sliding gates weighing up to 2500 kg that are up to 20-m long. RAL7024-grey cover.
120 V complete operators with 36 V DC geared motor
801MS-0330
BKV15RGS – High-performance operator with 36 V motor, featuring a control board with graphical display, Adaptive Speed & Torque Technology, four safety inputs, movement control and obstruction detection for gates up to 1500 in weight kg and 20 m in length.
BKV15RGS – High-performance operator with 36 V motor, featuring a control board with graphical display, Adaptive Speed & Torque Technology, four safety inputs, movement control and obstruction detection for gates up to 1500 in weight kg and 20 m in length.
801MS-0340
BKV20RGS – High-performance operator with 36 V motor, featuring a control board with graphical display, Adaptive Speed & Torque Technology, four safety inputs, movement control and obstruction detection for gates up to 2000 kg in weight and 20 m in length.
BKV20RGS – High-performance operator with 36 V motor, featuring a control board with graphical display, Adaptive Speed & Torque Technology, four safety inputs, movement control and obstruction detection for gates up to 2000 kg in weight and 20 m in length.
